|Size:||340mm×230mm×794mm||Sample Holder Can Be Tilted:||45°±2°|
|Copper Burning Cup:||OD 24mm ± 0.1 Mm, Wall Thickness 1mm ± 0.06mm Height 17mm ± 0.1mm, Volume 6mL||Fuel:||Chemically Pure Ethanol|
combustion testing equipment,
fire testing equipment
Stainless Steel Fireproof Coating Tester (small room method)
First, the scope of use
The instrument is suitable for quantitatively testing the flame retardant properties of fireproof coatings applied on the surface of substrates under laboratory conditions, and evaluating the advantages and disadvantages of fireproof coatings by the weight loss of combustion and the volume of carbonization.
Second, the main technical parameters
1. The dimensions of the instrument are about 340mm × 230mm × 794mm;
2. The sample holder can be tilted 45°±2°
3. Copper burning cup: outer diameter 24mm ± 0.1 mm, wall thickness 1mm ± 0.06mm height 17mm ± 0.1mm, volume 6mL
4. Fuel: chemically pure ethanol
Third, the list of goods
Instruction manual 1 copy
Fourth, the applicable standards
GB12441-2005 "Classification and Test Methods for Fire Performance of Finished Fire Retardant Coatings - Chamber Method"
