Sand dust test chamber for sale environmental test chamber Auto Testing Machine

Basic Information
Place of Origin: CHINA
Brand Name: BXT
Certification: CE ISO
Model Number: GLO-100
Minimum Order Quantity: 1SET
Price: negotiable
Packaging Details: wooden or carton packaging
Delivery Time: 5-8 work day
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 500 Piece/Pieces per Month Sand dust test chamber for sale
Detail Information
Application:: Environmental Test Chamber Product Name:: Sand Dust Test Chamber
Weight:: 160kg Temperature Range:: RT~+70(°C)
Power Supply:: 220V 50Hz Measurement Range:: 1s~99h Adjustable
High Light:

climatic test chamber


environmental test chambers

Product Description

Sand dust test chamber for sale



Sand and Dust Environmental Test Chamber is applied to all mechanic, electric, electronic, electric chemical and mechanical and electric equipments, it is used to evaluate whether equipment can resistivity and storage, running or not in air of dry sand or dust. It is applied toIEC-529, GB4208-93, GB2423.37-89 and GJB150.12.

Sand and Dust Environmental Test Chamber, large observation window with bright lights to keep the box, and use of tempered glass embedded heating element. Dust test chamber provides testing as per various iec 60529 for ip5x & ip6x, jis, is, dot mil standard, Combination of various testing cycles are available in a completely mono block construction. All settings can be done in an ergonomically designed control panel with accurate and uniform dust agitation.



1. Temperature range: RT ~ +70 ° C;
2. Temperature uniformity: ≤ 2 ° C;
3. Temperature fluctuation: ≤±0.5°C;
4. Metal screen nominal wire diameter: 50μm;
5. Nominal spacing between lines: 75μm;
6. Air flow speed: ≤2.5m/S;
7. Continuous cycle blowing dust can be arbitrarily selected for time setting, time range: 0-999 hours;
8. The dosage of talc powder: 2kg/m3~4kg/m3;
9. Test dust: dry talcum powder

10. Control Execution System: Adopt imported programmable time controller (Admiralty - Moeller) to effectively ensure that the test runs according to the standard
11. Equipped with vacuum to execute the components. (Vacuum meter, filter, gas flow meter, quick interface) Note: (excluding vacuum pump);
12. Ambient temperature: +15 ° C ~ 35 ° C;
13. Use relative humidity 45% ~ 85% R.H;
14. Standard configuration: 1. Observation window 2, test lead hole 3, moisture-proof lighting;
15. Safety device: leakage and power failure protection, overload fuse protection, fan overheat protection;
16. A socket that can be equipped with a corresponding dustproof electrical plug in the test work space;
17. Implementation of the standard. (GB-4208-93);
18. Power supply: AC380V±10% 50Hz.

Sand dust test chamber for sale environmental test chamber  Auto Testing Machine 0

Our Services

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.

1. Pre-service

24 Hours online service for your consult.

Help choose right model,and a series of service,person,advise.

2. Middle service

--Give you best offer

--Provide discount for many sets order

--Do customer's request:

--Choose payment term you convienent.

--Promptly production and delivery,inform you in time.

--Can provide invoice value as you like to decrease your tax.

3. After sale service

--1 year warranty service and all life maintenance.

--Technical Egineer are avalible for oversea trainning.

--Free change for some parts

--Remote control technical consult

--Free installation DVD

--Maintenance plan
