| Place of Origin: | CHINA |
|---|---|
| Brand Name: | BAXIT |
| Model Number: | BXT-NFB60DCB-4B-TT |
| Minimum Order Quantity: | 1unit |
| Price: | USD158/unit |
| Packaging Details: | Carton |
| Delivery Time: | 1-3working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 99999units |
| Model: | BXT-NFB60DCB-4B-TT | Voltage/Power: | 12Vor24V/10W |
|---|---|---|---|
| Electrical Machinery Life: | 20000H | Outlet Pressure: | 1bar |
| Under Pressure: | ≥-0.06Mpa | Positive Pressure: | ≥0.14Mpa |
| Gas Flowrate: | 2*700ml/min | Weight: | 422g |
| Noise: | 60dB | Work Temperature: | -8~45℃ |
| Delivery Lift: | 1bar | Pump Head Material: | PP |
| Highlight: | Liquid Diaphragm Pump,Wholesale Diaphragm Pump,DC24V Diaphragm Pump |
||
Principle:
Micro diaphragm pump is based on the principle of positive displacement pump simple design, by the motor through the transmission mechanism, to promote the diaphragm reciprocating motion, control the valve plate closed and opened, so as to form the water absorption and discharge of liquid.
| voltage/Power | 12Vor24V/10W | Electrical machinery life | 20000H |
| outlet pressure | 1bar | Under pressure | ≥-0.06Mpa |
| positive pressure | ≥0.14Mpa | Gas flowrate | 2*700ml/min |
| weight | 422g | Noise | 60dB |
| connection type | Plus or minus 2stage/ PWM control |
Work Temperature | -8~45℃ |
| Delivery lift | 1bar | Pump head material | PP |
| valve plate | EPDM/FPM/FFPM | Diaphragm | EPDM/PTFE/PTFE |
Typical applications:
Laboratory sampling, analysis and testing instruments; Medical equipment; Swimming pool equipment; Water quality analysis; Ceramic machine, UV machine, inkjet printing equipment, etc.
