Model: | BXT-WB-4 | Cavity Capacity: | 52L |
---|---|---|---|
Power Supply: | 220-240V AC50/60Hz 8A | Microwave Power: | 0-1600W |
Control Method: | 8-inch TFT-LED (800480 Color) Touch Screen | Operating System: | English |
Temperature Control Range: | 0-300°C | Temperature Control Accuracy: | ±0.5°C |
Temperature: | ≥300°C | Pressure: | ≥15000psi |
Material: | PTFE Material | Explosion-proof Outer Casing Material: | PEEK Aerospace Material |
High Light: | 220V Microwave Digester,Laboratory Microwave Digestion Instrument,High Temperature Microwave Digestion Instrument |
Product Parameters | ||||
BAXIT Microwave Digestion System | ||||
Model | BXT-WB-4 | BXT-WB-6 | BXT-WB-10 | BXT-WB-12 |
Cavity Capacity | 52L | |||
Cavity Material | 316 stainless steel chamber, can be sprayed with Teflon coating | |||
Power Supply | 220-240V AC50/60Hz 8A | |||
Microwave Power | 0-1600W | |||
Microwave Output Characteristics | Microwave non-pulse continuous automatic frequency conversion control, 0-100% automatic output | |||
Microwave Uniformity | Vertical bidirectional waveguide design, three-dimensional output technology, matching harmonic power frequency to achieve a high degree of field uniformity | |||
Control Method | 8-inch TFT-LED (800480 color) touch screen | |||
Operating System | English | |||
Temperature Control Range | 0-300°C | |||
Temperature Control Accuracy | ±0.5°C | |||
Pressure Control System | When the pressure exceeds the upper limit of the digestion tank, the pressure is automatically released and the gas is discharged through the exhaust fan. | |||
Pressure Control Accuracy | 0.01MPa, automatic adjustment/stop of microwave emission and automatic alarm for overpressure | |||
Temperature | ≥300°C | |||
Pressure | ≥15000psi | |||
Material | PTFE material | |||
Explosion-proof Outer Casing Material | PEEK aerospace material | |||
Inner Tube Reaction Volume | 72mL | |||
High Pressure Digestion Tank Batch Processing Capacity | ≥4 sample batches (can be upgraded to 40 bits without changing the rotor) | ≥6 sample batches (can be upgraded to 40 bits without changing the rotor) | ≥10 sample batches (can be upgraded to 40 bits without changing the rotor) | ≥12 sample batches (can be upgraded to 40 bits without changing the rotor) |
