| Power (w): | 220V/50Hz | Condition: | New |
|---|---|---|---|
| Type: | Portable | Use: | Vehicle / Tent |
| Color: | Gray And Blue | Function: | Cooling,Fast Air Cooling |
| Cooling Capacity: | 400m3/h | Power Consumption: | 1kw |
| Running Current: | 6A | Water Tank Capacity: | 14L |
| Body Size: | 450*510*1100mm | Package Size: | 520*570*1200mm |
| Gross Weight: | 65kg | Net Weight: | 60kg |
| Operating Ambient Temperature: | 18-45℃ | ||
| Highlight: | spot cooler ac,spot air cooler |
||
| Model | BXT-28 | BXT-45 | BXT-45D | BXT-50 | BXT-55 | BXT-65 | BXT-65B | BXT-85 | BXT-150 | BXT-180 | BXT-250 | |
| Power supply | Single phase 220V/50Hz |
Single phase 220V/50Hz |
Single phase 220V/50Hz |
Single phase 220V/50Hz |
Single phase 220V/50Hz |
Single phase 220V/50Hz |
Single phase 220V/50Hz |
Three phase 380V/50Hz |
Three phase 380V/50Hz |
Three phase 380V/50Hz |
Three phase 380V/50Hz |
|
| Refrigerating Output |
KW | 2.8 | 4.5 | 4.5 | 5 | 5.5 | 6.5 | 6.5 | 8.5 | 15 | 18 | 25 |
| BTU | 9650 | 15500 | 15500 | 16500 | 18700 | 22000 | 22000 | 36000 | 51100 | 61400 | 85300 | |
| Cold air output(m³/h) | 500 | 650 | 650 | 850 | 780 | 910 | 1100 | 1550 | 2700 | 4000 | 3500 | |
| Consumed power(KW) | 1 | 1.4 | 1.4 | 2.1 | 1.8 | 2.4 | 2.5 | 3.25 | 5.65 | 7.8 | 11.3 | |
| Current operation(A) | 5 | 7.4 | 7.4 | 10 | 10.4 | 10.8 | 11.5 | 7 | 13.2 | 15.8 | 20 | |
| Tank capacity(L) | 5 | 14 | 14 | 8 | 14 | 14 | 13 | External | External | External | External | |
| Product size(mm) | W 430 D 400 H 840 |
W 450 D 510 H 1100 |
W 450 D 510 H 1100 |
W 485 D 520 H 1180 |
W 520 D 625 H 1100 |
W 560 D 630 H 1260 |
W 520 D 575 H 1290 |
W 810 D 1050 H 1000 |
W 1360 D 810 H 1000 |
W 1400 D 810 H 1000 |
W 1405 D 900 H 1530 |
|
| Packing size(mm) | W 484 D 515 H 965 |
W 520 D 575 H 1210 |
W 520 D 575 H 1210 |
W 550 D 580 H 1300 |
W 610 D 700 H 1210 |
W 645 D 715 H 1575 |
W 630 D 700 H 1600 |
W 880 D 1120 H 1150 |
W 1430 D 885 H 1150 |
W 1480 D 885 H 1150 |
W 1480 D 980 H 1580 |
|
| Gross weight(kg) | 50 | 65 | 65 | 80 | 84 | 128 | 100 | 160 | 220 | 245 | 420 | |
| Net weight(kg) | 45 | 60 | 60 | 75 | 78 | 100 | 90 | 120 | 185 | 200 | 350 | |
![]()
![]()
![]()
![]()
![]()
If you encounter with any problems during the testing process,we promise providing urgent guidence and after-sales sevice within 48 hours and solution providing within 3 working days. If customers require on-site service, the transport and travel expense shall be responsible for the cost.
1. Pre-service
24 Hours online service for customers' consultation.
2. Middle service
-- Fullfill customer's request:
-- Payment method depends on customer.
-- Promptly production and delivery
-- Can provide invoice value if you want to decrease your tax.
3. After sale service
-- One year warranty service and all life maintenance.
-- Technical Egineer are avalible for oversea trainning.
-- Remote control technical consult
